用处与间介/Purpose and introduction：

NQGF型西林瓶粉针洗烘包装轧盖标贴纸签签联调线 由QCL国产直列V型超音波波洗瓶机、AQMR隧道施工式暖风嵌套循环系统杀菌真空烘箱、NQFGX国产精机丝杆粉剂包装机、NQ-50轧盖机、NQWTB-120标贴纸签签空气能机组成，也可单机联机选用。非常适合于7-25ml尺寸规格的西林瓶粉针的生产加工。能已完成喷洒放水、超音波波粗洗、瓶表面水擦拭器、瓶表面不断第多次嵌套循环系统水擦拭器、一回吹气、一回新鮮水擦拭器、不断第多次吹气、瓶表面吹气、的清洗、打火、烘干功能杀菌去热原、冷去、包装、加塞、轧盖、标贴纸签签等二十来道程序。NLGF schering bottles booster injection wash baked repackaging rolling cover labeling line consists of QCL series vertical ultrasonic bottle washer, ASMR tunnel type hot air circulation oven. NFFGX series CNC screw powder filling machine, NF-50 rolling machine, NFWTB-120 labeling machine, and also can be used stand-alone. Suitable for 7 to 25 ml specification schering bottles of water production. Can finish the spray water injection, ultrasonic thick bottle washing, the outer wall of water flushing, bottle wall continuous secondary circulating water flushing, a blowing, a fresh water rinse, two consecutive bottle blowing, blowing the outer wall, preheating and drying sterilization to pyrogen, cooling, packaging, gasser, cover, labeling and so on more than 20 procedures.

特征 /characteristic：

◆洗瓶机主要采用机诫手夹瓶，适于许多規格的西林瓶；Bottle washer adopts manipulator clamp bottle, is suitable for a variety of specifications of schering bottles;◆洗瓶选取水汽喷针导杆侦测插进模式，难以清理效率好，勤俭节约电力能源。并拥有针架防抽动平衡装置，提升喷针插进塑料瓶的精确性度，避免断针现状进行；Reciprocating mixer washing bottle with water spray needle track insert way, cleaning effect is good, save energy. And is equipped with needle shake device, improve the accuracy of injection needle inserted into the bottle, reduce breakage phenomenon;◆洗瓶整体的热气管道、喷针彻底独自分别，逃避了重叠污染破坏，按照GMP规范化规范；Mixer washing bottle the water pipe, injection needles completely separate, to avoid the cross contamination, in line with the GMP requirements;◆洗瓶机进瓶螺丝杆前改加保护区块，有保护区螺丝杆，可以减少碎瓶目的；Pieces into the bottle inside the screw before adding buffer block, protect the screw, reduce broken bottle;◆洗瓶机出瓶适用整个国外进口同步操作带，连入拨瓶块输送机西林瓶，启用增强牢靠；Pieces out of the bottle inside the whole import synchronous belt, the connection dial the bottle conveying schering bottles, operation is stable and reliable;◆烘干箱通过内嵌套循环嵌套循环加熱，室温不匀，节省；Oven adopts hot air circulation heating, temperature uniformity, energy saving;◆烤箱拥有防无缘无故没电保护的功能模块。启动安全性；Mixer oven has suddenly loses power protection function. Run security;◆烘干箱可配循环往复水冷式系统，不材料耗费房风口尺寸，减低房的气体压力不平衡量的隐患提温成果好；Mixer oven can match circulating water cooling device, not loss room air volume, reduce the risk of differential pressure imbalance in room cooling effect is good.◆烘烤箱可配风压差大自己动失衡上下调整系统软件减低室内和烘烤箱的风压差大不动失衡从而造成的中高温段倾斜，灌装设备间洗烘间环境温度升高等专科学校一国产的状况；Mixer automatic oven can match differential pressure balance control system to reduce the room and high temperature oven pressure difference caused by the imbalance of period of migration, filling between wash between baking temperature and so on a series of problems;◆烘干箱有DOP查重usb接口(还包括压力、风速等级、尘沙离子查重口)；Mixer oven with DOP test interface (including wind pressure, wind speed, dust particle detection);◆真空烘箱放凉段可带线过滤除菌实用功能(FDA特选)；Mixer oven cooling segment with the function of sterilization (FDA selected);◆烘烤箱网带可带超声波蔓延到CIP上线清理系统的；Type mixer oven mesh belt with ultrasound scanning CIP online cleaning system;◆烤箱内腔室可开始全定位、多立场油田水情况呢；In pieces inside the oven chamber can be all-round, multi-angle high-pressure water flushing;◆分开装袋机用国家更一流的设计构思心理，兼具稳定度，可是分瓶最准确，换个标准件简单；Mixer racking machine adopts the most advanced design concept, high speed, and bottles of accurate, replacement of a convenient;◆散装机利用聊天交流伺服电动机电动机推动散装螺栓滑动，装量精密；Mixer racking machine adopts ac servo motor drive the repackaging screw rotation, the load accurately;◆全自动灌装机机进行装量的懂得调整可以直接在接触屏上做到；Mixer packer adopts the load adjustment directly on a touch screen;◆分开装袋机可选择配百级配置式层流罩；Mixer packer optional circulating laminar flow hood best level;◆全自动灌装机机无瓶立即停止全自动灌装机，无瓶不带塞功效。Racking machine without stop packing bottle, no bottle no stoppered function.◆整线使用PLC总管控、直流变频空调器、手触屏管控技術，正常行驶稳定性安全可信。手触屏可彰显各pc单机的正常行驶的情况，各管控点的通水压力、气压、气压、温等彰显，各按钮的情况和出现问题的彰显，出现问题的个人能力检测和出现问题的进行分析及解决手段。使正个产生期间完成一键化管控，联线兼具自动化动态平衡设施，提高产生动态平衡安全可信。The whole line adopts PLC control, inverter, touch screen control technology, stable and reliable running. Touch screen can display the running state of each units, each control point of the water pressure, air pressure, air pressure, temperature, etc, according to the switch state and fault display, fault self-diagnosis and fault analysis and elimination method. Make the whole production process automation control, on-line has the automatic balancing device, ensure production equilibrium is reliable.据客的要有，还可供选型：According to the needs of customers, but also available for selection:◆西门子PLC、德力西、三凌、台达等公司保持软件系统；Pieces of Siemens, schneider, mitsubishi, Taiwan brands such as control system;◆水、气经济压力、温度及mri波标准、尘灰水粒子、风速等级再线查重、报警声音、收录、打印机机系统；Pieces of water, gas pressure, water temperature and the intensity of ultrasonic, dust particles, wind speed on-line detection, alarm, record and print system;◆ORABS、CRABS、无茵屏蔽器系統。ORABS, CRABS, aseptic isolator system.

技能技术指标：/technical parameters

款式 model

制造学习能力production capacity

洗瓶通过率率Washing bottle percent of pass

洗瓶碰坏率Washing bottle breakage

无菌气温sterilizing temperature

预包装误差值The repackaging of error

加塞通过率率Gasser percent of pass

冷空气层流是否干纯度Laminar air cleanliness

真空室抽速Vacuum pumping speed

电感量 capacitance

电源适配器power supply

总电池寿命Total transmission energy

外表尺寸大小boundary dimension

7-25ML执行标准西林瓶 7-25ML GBvial

300瓶pcs/分min ～600瓶pcs/分min

≥99%

≤0.1%

300℃-350℃

≤±3%(0.1-10h)

≥99%

100级100c

25m3/H(外配)100cbm/H ～50m3/H(外配)100cbm/H

96kw～235.5kw

380v,50HZ

约 8200KG

约 2000×1750×2370mm
