使用与详细资料/Brief Introduction：

该线由美式螺旋轴洗瓶烘干处理功能分离式机、口服药液分装轧盖机二台电脑pc单机组成部分，为洗掉、干热无菌和分装塑封3个操作区，全部可联动机制生产加工，也可电脑pc单机施用。可达成淋水、超声检查波洗掉、冲水、冲气、烘干处理功能无菌、保压、分装、理盖、戴盖、轧盖等流程。The line is made up of two single machine, one straight-line screw bottle washing and drying machine and one oral liquid filling and capping machine. The line is divided into cleaning, drying, sterilization and filling sealing three workspace, all can joint production, also can use single. It can complete water spray, ultrasonic cleaning, water flushing, air flushing, drying sterilization, cooling, filling, cap arranging, capping, sealing, etc.

显著特点/Characteristic：

主要采用超声洁净波洁净及雾气变换冲干净、远红外高温天气无菌、双头装灌与塑封等技木。整线联动性系统自动把控好。运行简约便利，控制了电气混合式化。Using ultrasonic cleaning and water washing alternately, far-infrared high-temperature sterilization, such as long filling and sealing technology. The automatic control of the whole line linkage. Simple and convenient operation, electromechanical integration is realized.

技術因素/ Technical Parameters：

生产能力technical parameters	80-150瓶/分80-150 bottles/min
支持規格 Cutting dimension	5-20ml
电  容  量Amount of electric capacity	65Kw(这里面一切⛄正常上班36Kw)(including normal working ༒36 kw)
机气毛重machine net weight	6800Kg
外形尺寸boundary dimension	9650×2360×1900mm（长×宽×高）(length x width x height)
